| Tauira |
Q-60B |
Q-60C |
Q-60D |
| Putanga |
Tau Putanga |
Ch1 |
Ch2 |
Ch3 |
Ch4 |
Ch1 |
Ch2 |
Ch3 |
Ch4 |
Ch1 |
Ch2 |
Ch3 |
Ch4 |
| DC ngaohiko |
5V |
12V |
-5V |
-12V |
5V |
15V |
-5V |
-15V |
5V |
12V |
24V |
-12V |
| Kua whakatauhia o naianei |
5.5A |
2A |
0.5A |
0.5A |
5.5A |
1.5A |
0.5A |
0.5A |
4A |
1A |
1A |
0.5A |
| Awhe o naianei |
0-8A |
0.1-2A |
0-1A |
0-1A |
0.5-6A |
0.1-2A |
0-1A |
0.5-1A |
0.5-6A |
0.1-3A |
0.1-1.5A |
0-1A |
| Te mana whakatau |
60W |
60W |
62W |
| Ripple&haruru |
100mVp-p |
120mVp-p |
100mVp-p |
120mVp-p |
100mVp-p |
120mVp-p |
100mVp-p |
120mVp-p |
100mVp-p |
120mVp-p |
100mVp-p |
100mVp-p |
| Ngaohiko adj.range |
Ch1+10,-5% |
| Whakaaetanga ngaohiko |
±2.0% |
±6.0% |
±5.0% |
±5.0% |
±2.0% |
±4.0% |
±5.0% |
±5.0% |
±2.0% |
±6.0% |
±4.0% |
±5.0% |
| Whakaritenga raina |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±2.0% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±2.0% |
±0.5% |
| Whakaritenga kawenga |
±0.5% |
±4.0% |
±1.0% |
±1.0% |
±0.5% |
±4.0% |
±1.0% |
±1.0% |
±0.5% |
±0.5% |
±4.0% |
±1.0% |
| Whakaturia, wa whakatika |
800ms,20ms/230VAC 1600ms,20ms/115VAC(katoa te uta) |
| Kia mau te wa（Typ.) |
70ms/230VAC 15ms/115VAC(katoa te uta) |
| Whakauru |
Awhe ngaohiko |
85~264VAC ranei 120~373VDC |
| Auautanga |
47 ~ 63Hz |
| Te kaha |
70% |
72% |
75% |
| AC nāianei |
2A/115VAC 0.8A/230VAC |
| Kokuhi o naianei |
Te tiimata makariri: 15A / 115VAC 30A / 230VAC |
| Leakage ia |
<1mA/240VAC |
| Parenga |
Te taumahatanga |
Kua whakatauhia te mana whakaputa 105%~150% |
Momo whakamarumaru: Aratau Hiccup, ka ora aunoa i muri i te tango i te ahua he
|
| Neke atu i te ngaohiko |
5V:5.75~6.75 |
Momo whakamarumaru: Aratau Hiccup, ka ora aunoa i muri i te tango i te ahua he
|
| Taiao |
Te pāmahana mahi |
-10℃～+60℃ |
| Te haumākū mahi |
20-90%RH |
| Te pāmahana rokiroki, te haumākū |
-20~+85℃，10%-95%RH |
| Temp.coefficient |
±0.03% ℃(0-50 ℃)(+5V) |
| Wiri |
10 ~ 500Hz, 2G 10min./1hurihuri, 60min. ia toki X, Y, Z |
Haumaru
&
EMC |
Nga paerewa haumaru |
Tautukunga ki: CE me GB4943.1 paerewa haumaru |
| Tuturu ngaohiko |
I/PO/P:1.5KVAC 1meneti I/P-FG:1.5KVAC 1meneti O/P-PG:0.5KVAC 1meneti |
| Te aukati wehe |
I/PO/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH |
| EMC tuku |
EN61000-3-2:2014/EN61000-3-3:2013 |
| EMC aukati |
EN 55032:2015/EN55035:2017/60950-1 |
| Ko etahi atu |
MTBF |
≥284.8K haora MIL-HDBK-217F(25 ℃) |
| Rahi |
L159*W98*H38mm |
| Te takai |
0.45KG |
| Tuhipoka |
1. Ko nga tawhā katoa KORE i whakahuahia ka inehia ki te whakaurunga 230VAC, te utaina kua tohua me te 25 ℃ o te pāmahana ambient.
2. Ka inehia te Ripple&haruru ki te 20MHz o te bandwidth ma te whakamahi i te 12 'tawhiowhio takirua -waea kua whakamutua ki te 0.1uf me te 47uf nga punga whakarara.
3. Whakaaetanga:kei roto i te whakatuu whakararu, te tikanga raina me te ture uta. o nga waahanga kei roto i te punaha ka whakamatautauhia nga tauira
whakamatautau
i runga i te pereti rino me te matotoru o te 1mm, te roa o te 360mm * te whanui o te 360mm. |
|
|
|
|
|
|
